Rated insulation voltage: AC250V
Rated operational voltage: AC220V
Rated operational current (Ie): 30A, 50A, 75A, 100A, 200A, 300A, 400A
Number of poles: 2P, 3P, 4P *
Connection: Front, Back
Kind of throw: Double throw
Operating voltage: AC100/110V, AC200/220V, DC100/110V
Auxiliary switch: 1C/each side
Accessories: Main terminal cover (only front connection), Manual handle, Surge absorber, Flush plate (for only back connection)

Feature
・If the optional limiting resistance is connected, it can be paused at the neutral position for maximam 30 seconds.
*4P is not supported for 300A and 400A.
